OpenPyXL is a Python library that reads and writes Excel workbooks directly, with no Excel installation required. This guide walks through real automation tasks: building reports, formatting cells, adding formulas and charts, and processing large files.
Why openpyxl and not something else
Three libraries dominate Python-to-Excel work. xlrd/xlwt handle the legacy .xls format and are essentially frozen. xlsxwriter writes files beautifully but cannot read or modify existing workbooks. pandas is superb for data analysis and can read/write Excel via its openpyxl engine, but it drops charts, conditional formatting, and precise styling on round-trips.
OpenPyXL sits in the middle: full read/write access to modern .xlsx files, including formatting, formulas, charts, data validation, and filters. It runs anywhere Python runs, including Linux servers with no Office installed. That combination makes it the default choice for report automation.
1. Install openpyxl and create your first workbook
Install it with pip:
pip install openpyxlA minimal script creates a workbook, names the active sheet, adds data, and saves it:
import openpyxl
wb = openpyxl.Workbook()
ws = wb.active
ws.title = "Sales"
ws.append(["Date", "Product", "Units", "Unit Price"])
ws.append(["2026-09-01", "Widget", 10, 2.50])
ws.append(["2026-09-02", "Gadget", 3, 4.00])
ws.append(["2026-09-03", "Gizmo", 2, 9.00])
wb.save("sales.xlsx")Every workbook starts with one sheet accessible as wb.active. ws.append() writes a whole row at once, and ws["A1"] = "value" targets a single cell. Save with wb.save() — nothing is written to disk before that call.
2. Read and process an existing file
Opening a file is one line. Use iter_rows() to walk the data without loading cell objects you do not need:
from openpyxl import load_workbook
wb = load_workbook("sales.xlsx")
ws = wb.active
for row in ws.iter_rows(min_row=2, values_only=True):
date, product, units, price = row
print(product, units * price)min_row=2 skips the header row, and values_only=True returns plain Python values instead of cell objects — faster and cleaner. To reach a specific sheet by name, use wb["Sales"] or wb["Sheet2"].
A common pattern: read one workbook, transform rows in Python, and write the results to a second workbook. This is how people automate monthly reconciliation reports that currently eat half a day of manual copy-paste.
3. Write formulas (openpyxl does not calculate them)
Set a cell's value to a string starting with = and Excel treats it as a formula:
ws["E1"] = "Line Total"
for row in range(2, ws.max_row + 1):
ws[f"E{row}"] = f"=C{row}*D{row}"
ws["F1"] = "Grand Total"
ws["F2"] = "=SUM(E2:E100)"Important: openpyxl only writes the formula text. It does not evaluate it. When the file is opened in Excel, LibreOffice, or Google Sheets, the application calculates the results on first load. If another Python script reads the file afterwards and you need the calculated values, pass data_only=True to load_workbook() — this reads the last cached values that Excel saved.
4. Format cells like a professional report
Formatting lives in openpyxl.styles. Build reusable style objects and apply them to cells:
from openpyxl.styles import Font, PatternFill, Alignment, Border, Side
header_font = Font(name="Calibri", bold=True, color="FFFFFF")
header_fill = PatternFill(start_color="1F4E78", end_color="1F4E78", fill_type="solid")
thin_border = Border(
left=Side(style="thin"), right=Side(style="thin"),
top=Side(style="thin"), bottom=Side(style="thin"),
)
for cell in ws[1]:
cell.font = header_font
cell.fill = header_fill
cell.alignment = Alignment(horizontal="center")
cell.border = thin_borderws[1] returns every cell in row 1, so one loop styles the whole header. For numbers and dates, set cell.number_format — "#,##0.00" for currency-style values, "YYYY-MM-DD" for dates, "0%" for percentages.
Column widths need a touch too, since openpyxl does not auto-size columns. Use get_column_letter from openpyxl.utils:
from openpyxl.utils import get_column_letter
for col in ws.columns:
letter = get_column_letter(col[0].column)
ws.column_dimensions[letter].width = max(
len(str(cell.value or "")) for cell in col
) + 2This measures the longest value in each column and sizes the column to fit — the closest thing to Excel's auto-fit available in pure Python.
5. Add conditional formatting and charts
Conditional formatting flags outliers without manual inspection. Highlight every line total above 25:
from openpyxl.formatting.rule import CellIsRule
from openpyxl.styles import PatternFill
red = PatternFill(start_color="FFC7CE", end_color="FFC7CE", fill_type="solid")
ws.conditional_formatting.add(
"E2:E100",
CellIsRule(operator="greaterThan", formula=["25"], fill=red),
)Charts are native Excel objects, not images — recipients can hover over data points and restyle them:
from openpyxl.chart import BarChart, Reference
chart = BarChart()
chart.title = "Units Sold"
chart.style = 10
data = Reference(ws, min_col=3, min_row=1, max_row=ws.max_row)
chart.add_data(data, titles_from_data=True)
ws.add_chart(chart, "G2")titles_from_data=True takes the header in row 1 as the series name. The chart anchors at cell G2 and moves with the sheet like any manually inserted chart.
6. Data validation and sheet protection
Restrict a column to a dropdown list so downstream users cannot break your report:
from openpyxl.worksheet.datavalidation import DataValidation
dv = DataValidation(type="list", formula1='"Approved,Pending,Rejected"', allow_blank=True)
dv.error = "Please pick a value from the list"
ws.add_data_validation(dv)
dv.add("B2:B100")Lock the sheet with a password while leaving input cells editable:
ws.protection.sheet = True
ws.protection.password = "secret"
ws["C2"].protection = openpyxl.styles.Protection(locked=False)A subtle point: protection on individual cells only matters once the sheet itself is protected. The pattern is to lock everything, then unlock the cells users are meant to fill in.
7. Handle huge files without freezing
The default mode holds the entire workbook in memory. For files with hundreds of thousands of rows, use streaming modes:
load_workbook("big.xlsx", read_only=True)streams rows instead of loading everything — ideal for processing exports row by row.Workbook(write_only=True)streams rows straight to disk while writing — ideal for generating massive files.
from openpyxl import Workbook
wb = Workbook(write_only=True)
ws = wb.create_sheet()
for i in range(500_000):
ws.append([i, f"row-{i}", i * 1.5])
wb.save("huge.xlsx")Streaming has trade-offs: read-only workbooks cannot be modified in place, and write-only workbooks cannot read back what was written. Use them for pipelines, not interactive editing.
OpenPyXL limits worth knowing
No library is magic. OpenPyXL works only with the modern .xlsx format, not legacy .xls files. It cannot run VBA macros, refresh pivot tables, or recalculate formulas — those need Excel itself. If you need Excel to execute macros on Windows, xlwings drives the real application via COM and complements openpyxl rather than replacing it.
